A1304ELHLX-T

supply_voltage_min_v

3

supply_voltage_max_v

3.6

technology

Hall

output_type

Analog

typical_sensitivity_mv_per_g

4

typical_sensitivity_mv_per_mt

5, 40

ratiometric

Yes

sensitivity_error

±1.5

quiescent_output_typical_v

50% Vref

output_bandwidth_typical_khz

20

temp_ranges

-40°C to 85°C

programming

Factory Programmed

package

3-Pin SOT23W

market

Industrial

sensitivity_reference_voltage

3.3

customer_programmable

No
