Top Features
- 无需外部感应电阻，单独封装方案
- 更低功率损耗：
- 0.6 mΩ 内部导体电阻（EX 封装）
- 1.2 mΩ 内部导体电阻（LC 封装）
- 经济型低端及高端电流感应
- 输出电压与交流或直流电流成比例
- ±12.5 A 和 ±25 A 全刻度感应范围（LC 封装）
- ±15.5 A 和 ±31 A 全刻度感应范围（EX 封装）
- 过流故障跳闸，在 100% 满标电流时锁定
- 低噪音模拟信号路径
- 100 千赫带宽
- 小型低厚度 SOIC8 和 QFN 封装
- 3.0 至 5.5 V, 单电源工作
- 集成静电屏蔽，保持输出稳定
- 出厂时已经校准，确保精确度
- 极度稳定的输出偏移电压
- 零磁滞
- 电源电压的成比例输出
Part Number Specifications and Availability
ACS711 Product Overview
The Allegro ACS711 provides economical and precise solutions for AC or DC current sensing in 100+ V audio, communications systems, clean energy, personal mobility and white goods. The device package allows for easy implementation by the customer.
The device consists of a linear Hall sensor circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction path generates a magnetic field which is sensed by the integrated Hall IC and converted into a proportional voltage.
