A81411 集成了升降压预稳压器、五个线性稳压器（包括具有电池短路保护 LDO）以及 SPI 控制接口，简化了汽车电源设计，具备灵活配置和诊断能力。
Product Details
Product Details
Top Features
- A2-SIL™ product: Developed as a hardware safety element out of context with ASIL D capability for use in automotive safety-related systems
- Automotive AEC-Q100 Grade 0 qualified
- Wide input range: 3.2 to 36 V VIN operating, 40 V VIN maximum
- 2.2 MHz synchronous buck-boost preregulator (VREG: 5.35 V) with internal compensation
- Five internal linear regulators with fold-back short-circuit protection
- VUC: 3.3 V or 5 V (selectable by a pin) regulator for microcontroller
- VLDOA: 5 V (or 3.3 V factory option) general-purpose low-dropout (LDO) regulator
- VLDOB: 5 V or 3.3 V (selectable by a pin) always-on LDO regulator
- VLDOP1 and VLDOP2: Two programmed (5 V or 3.3 V) and enabled via serial-port-interface (SPI) LDO regulators with short-to-battery protection for remote sensors
- Pulse-width watchdog (PWWD), window watchdog
