Integrated Current Sensors
Our integrated current sensors combine precision measurement with built-in isolation for compact, high-efficiency designs. By replacing bulky shunt and amplifier setups, they simplify layouts, reduce heat, and enhance safety across automotive and industrial applications.
Featured Products
ACS37100
Explore how Allegro's ACS37100 is fully integrating TMR current sensor by offering high accuracy and low noise for demanding control loop applications.
ACS37002
400 kHz, High Accuracy Current Sensor with Pin-Selectable Gains
ACS71240
Automotive-Grade, Galvanically Isolated Current Sensor IC
ACS37800
Programmable AC and DC Power Monitoring IC
Product Selection Guide
Documentation & Resources
Application Note
New Approaches to High-Efficiency Current Sensing: Integrated Hall Sensor ICs Save Power and Space
AN296100: Allegro current sensor ICs allow design engineers to use Hall-effect based current sensor ICs in new applications where increased energy efficiency or new operating features are required. Wherever current sensing is needed, an integrated Hall-effect IC can provide a solution.
Application Note
Improved Performance and Features of Allegro’s Next Generation, High Power Density CB Package Current Sensors
This application note will describe the use of the new high current ACS772 Hall-effect current sensor integrated circuit (IC) from Allegro MicroSystems and will give an overview
of its features and improvements from previous Allegro high-current sensors.
Application Note
Improving Efficiency in Smart Grid Applications With Fully Integrated Current Sensing ICs
With increasing concerns about the global demand for energy and environmental awareness, power electronics applications are under pressure to improve efficiency.
Technical Article
Hall Effect Current Sensing in Hybrid Electric Vehicle (HEV) Applications
This note provides an understanding of hybrid electric vehicle (HEV) power systems and the contribution Hall-effect sensing technology can provide to improving the performance and cost-effectiveness of these systems.
Application Note
Achieving Closed-Loop Accuracy in Open-Loop Current Sensors
Closed-loop current sensing technology is employed in many industrial and automotive applications for accurate current sensing. Allegro MicroSystems has developed magnetic-based current sensor IC solutions that achieve near closed-loop accuracy using an open-loop topology.
Application Note
A Micro-Packaged Linear Current Sensor IC
Traditionally, current sensing has been accomplished with sense resistors or current transformers that can take up a large PCB area. Sense resistor values from 10 to 50 mΩ can burn a significant amount of power at higher currents.
Application Note
Techniques to Minimize Common-Mode Field Interference When Using Allegro Current Sensor ICs (ACS724 and ACS780)
This application note will discuss the mechanism of CMR and focus on how to best use this mechanism through optimized circuit board design and layout for sensors that need an external magnetic core, sensors that have a core built into the package, and sensors that have an integrated current-carrying loop but no core.
Application Note
Shifting the Offset Voltage of Current Sensors
Most of the Allegro™ unidirectional current sensor ICs are trimmed such that the zero ampere output is at 0.1 × VCC . The advantage of having the output voltage at 0.1 × VCC is that the output can swing slightly lower than this value before saturating.
Application Note
Recent Trends in Hall-Effect Current Sensing
This paper presents recent advances in integrated Hall-effect–based current sensor ICs. It covers the various packaging concepts for integrating the primary current path into the system, the major improvements in IC parameters.
Application Note
Allegro MicroSystems - Managing External Magnetic Field Interference When Using ACS71x Current Sensor ICs
The highly compact Hall effect current sensor ICs without concentrators that are now available make it possible to enhance performance of small-current differentiation by simple layout steps and shielding the device from extraneous magnetic flux along its primary sensing axis.
Application Note
Hall Effect Current Sensing in Electric and Hybrid Vehicles
Improved energy efficiency in HEVs and EVs can be attained by using electrically-driven actuators instead of belt-driven and hydraulic actuators. For instance, in traditional internal combustion engines a fan belt drives the cooling fan, which operates continuously while the engine is running.
Technical Article
Current Sensing For Renewable Energy
In grid-tied photovoltaic systems, designers must focus on minimizing cost per watt to deliver the best possible return on investment.
Application Note
Common Mode Field Rejection in Coreless Hall-Effect Current Sensor ICs
Allegro current sensor ICs use the Hall-effect to measure the magnetic field produced by an integrated, current-carrying loop, translating the magnetic field to a voltage which is proportional to the current flow.
Application Note
Differential Current Sensing with the 1 MHz Bandwidth ACS733
AN296154 - This application note describes the use of the new highly isolated, high bandwidth ACS733 Hall-effect current sensor integrated circuit (IC) from Allegro MicroSystems and gives an overview of its features and advantages over a highspeed current transformer (CT) current sensing solution.
Application Note
An Effective Method for Characterizing System Bandwidth in Complex Current Sensor Applications
This application note describes multiple methods for measuring
and characterizing system bandwidth, with a focus on
the impulse response method. Allegro’s ACS720 is the perfect device to validate the test methods outlined here.
