Low Jitter, 24V Hall-effect Latches for Automotive and Industrial Applications

APS12203

Markets Served

The APS12203 is a third generation Hall-effect latch featuring industry leading low jitter performance and chopper-stabilization for precision performance over both industrial and automotive temperature ranges. The APS12203 incorporates Allegro’s latest design and manufacturing technologies to deliver an unprecedented level of performance across automotive, industrial and consumer applications.

View Datasheet

Product Details

Top Features

  • 2.7 to 26V operation
  • AEC-Q100 qualified
  • High and low sensitivity magnetic switch point options
  • Choice of output polarity
  • Chopper stabilization Low switch point drift over temperature
  • Insensitive to physical stress
  • Open drain output
  • Industry-standard package and pinout
  • Reverse voltage and short circuit protection
  • Low jitter

Part Number Specifications and Availability

View Full Specification Details

APS12203KMDALX-0SL0

supply_voltage_min_v
2.7
supply_voltage_max_v
26
operating_point_bop_max_g
20
release_point_brp_min_g
-20
average_supply_current_ua
1.5
output
Voltage
sensor_type
1D Planar
temp_ranges
-40°C to 125°C
aec_q100
Yes
asil_rated
No
packages
3-Pin SOT23W
market
Industrial
typical_bop
-
typical_brp
-
