A80800-2 提供紧凑高效的汽车 LED 照明方案，恒流输出高达 2A，支持 PWM 调光，集成 MOSFET 开关以简化设计。
Product Details
Product Details
Top Features
- 55Vin rating – Can be used on traditional 12-V automotive, and 24-V trucks, and systems using a pre-boost supply followed by the A80800-2 to drive a high number of LEDs
- Integrated FETs – No need for external FET(s) or Diode as part of the buck conversion, and higher efficiency
- Switching frequency dithering for EMI reduction – pass OEM requirements and minimize associated components
- 5V Vcc can be used to source up to 14mA as a local rail (e.g., power a small uC) – potentially eliminate an LDO
Target Application
