集成 ARM M4 Cortex MCU 的 90V 汽车三相电机驱动器

• 5.5 to 90V supply voltage operating range
• 32-bit, 40MHz ARM Cortex M4 CPU Core
• Up to 256kByte Flash, 32kByte DRAM
• 80MHz PWM Generator
• 3-phase bridge MOSFET driver with bootstrap gate drive for N-channel MOSFET bridge
• Programmable 3-channel Current Acquisition Unit (CAU) for BLDC motor
• 12-bit 1μs Data Acquisition Unit (DAU) for voltage measurement
• 1-phase BEMF detector
• Automotive AEC-Q100 qualified

On-Chip Memory

• 32kByte DRAM
• 8kByte IRAM
• 32kByte Boot ROM
• On-chip ±1% accurate oscillator
• Programmable clock generator
• One clock per machine cycle architecture
• DMA • 16 Level Interrupt Handler
• SW-DP 2-wire debug
• Charge pump for low supply voltage operation.
• 3.3V or 5V CMOS compatible logic I/O • 12-bit PWM at 20kHz
• Programmable bemf and current sample control
• Programmable high-performance current sense amplifier
• 3 x 12 bit, 1μs ADC for current measurement
• 8 general purpose I/O ports (GPIO)
• 8 General purpose timers
• 2 Serial Communication Interfaces (SCI)
• LIN Data Link Layer
• 1-phase BEMF detector
• Integrated power management
• VDS, UVLO, and thermal shutdown Diagnostic
• Latched TSD with fault output
