絶縁ゲート ドライバー

GaN、MOS、SiC 用の完全な統合絶縁ゲート ドライバー

GaN および SiC パワー デバイスは、電気自動車およびグリーン エネルギー用途で瞬く間に市場シェアを獲得することが期待されています。 2022 年の Heyday の買収によって取得した Allegro の絶縁ゲート ドライバー ソリューションは、絶縁ゲート ドライバー、絶縁電源、および関連する受動素子を統合したフットプリントの小さい単一のパッケージを使用します。 これにより、システム設計の時間と複雑さが大幅に軽減され、設計者は、WBG スイッチが提供するすべての効率のメリットを活用できます。 さらに、システムの設計時間と複雑さが軽減されるため、追加のエンジニアリングや設計リソースの必要性が軽減されます。

シンプルさのメリット

当社の電源内蔵型デバイスは高速ゲート ドライバーと絶縁電源のすべてを 1 つのパッケージで提供します。

  • ブートストラップ コンポーネントを排除
  • 大きな DC-DC 絶縁電源モジュールを解消
  • 新しい性能と効率のレベルを解放



次のことを達成できます。

PCB comparisons between competitor and Allegro Power Thru technology



すべて一度に

パワースルー技術

 パワースルー 技術 を採用した Allegro ゲート ドライバーは、実績のある CMOS シリコン技術を基にして構築され、MOSFET だけでなく、GaN FET や SiC FET などの新しいワイド バンドギャップも駆動させることができます。

詳細をご覧ください

HV Isolated Evaluation Boards

EVK PN Switch Supplier / PN Description Gate driver used Check free sample eligibility
EVK nameAPEK85110KNH-01-T-MH SwitchE-Mode GaN Supplier / PNGaN Systems GS66516B DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85110 Samplescontact our sales team
EVK nameAPEK85110KNH-05-T-MH SwitchE-Mode GaN Supplier / PNNexperia GAN080-650EBE DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85110 Samplescontact our sales team
EVK nameAPEK85110KNH-06-T-MH SwitchCascode GaN Supplier / PNTransphorm TP65H070G4QS DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85110 Samplescontact our sales team
EVK nameAPEK85111KNH-02-T-MH SwitchE-Mode GaN Supplier / PNGaN Systems GS66508B DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85111 Samplescontact our sales team

The Power of Simplicity

Our self-powered devices provide high-speed gate driver & isolated supply all in one package.

  • Say goodbye to bootstrap components
  • Remove bulky DC-DC isolated power modules
  • Significantly reduce EMI noise and common mode capacitance
  • Achieve higher efficiency and higher power-density than with any other solution
  • Simply enable the higher performance of multilevel topologies, by removing most complexity
electric vehicle charging on station fueled by isolated gate drivers

Allegro's Power-Thru technology is an Optimal Choice for Engineers Working with GaN and SiC devices

Learn how our Power-Thru technology simplifies high-power system design, reduces costs and enhances performance.

Watch the video from the PCIM Conference 2024.

0:00



This is what YOU can achieve

PCB comparisons between competitor and Allegro Power Thru technology



All at once.

Power-Thru Technology

Featuring our Power-Thru technology, Allegro gate drivers are built on proven CMOS silicon technology and can drive MOSFETs as well as the new wide bandgap GaN and SiC FETs.

Watch our video to learn more

0:00

HV Isolated Evaluation Boards

EVK PN Switch Supplier / PN Description Gate driver used Check free sample eligibility
EVK nameAPEK85110KNH-01-T-MH SwitchE-Mode GaN Supplier / PNGaN Systems GS66516B DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85110 Samplescontact our sales team
EVK nameAPEK85110KNH-05-T-MH SwitchE-Mode GaN Supplier / PNNexperia GAN080-650EBE DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85110 Samplescontact our sales team
EVK nameAPEK85110KNH-06-T-MH SwitchCascode GaN Supplier / PNTransphorm TP65H070G4QS DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85110 Samplescontact our sales team
EVK nameAPEK85111KNH-02-T-MH SwitchE-Mode GaN Supplier / PNGaN Systems GS66508B DescriptionHalf-bridge bipolar driver-switch board Gate driver usedAHV85111 Samplescontact our sales team



Allegro Driver Recommended by GaN Systems in Bodo's Power System December Issue

The AHV85110 (Hey1011) gate driver is recommended as the 1st step to achieve highly-effective GaN designs.



Read full article here

Creating Superior Modules

Achieve Low Common Mode Capacitance

Typically 10 to 15x smaller than competition

Increase Power Density

Typically 15 to 50% more power in the same volume

Reduce Component Count

Typically 20 to 50% less BOM count

Create the Most Simple and Integrated Solution

With up to 40% less different components per system compared to a solution with GaNFET with integrated driver

Reduced Bias Power Consumption

Typically save 50 to 65% and up to 1.5W per half-bridge

Unlock the Advantages of Multilevel Topologies

Removing the need for multiple isolated power rails make your multilevel design feel nearly as easy as child's play. Allegro's Power-Thru technology let you achieve ultra-high power-density and efficiency at lower cost without the complexity.

Unique Gate Driver Benefits

No need for an isolated supply

With Allegro's isolated driver you don't need a separate isolated supply.  This means lower BOM count, less PCB area and improves the robustness and EMI performance of your converter.

Short propagation time

Both the ON and OFF propagation times are very short (25ns typ).  This makes dead-time management between switch cycles easy to manage and helps to maximize the efficiency of the power converter.

Continuous ON time capability

Would you like to drive your switch ON or OFF for a long time without having to worry about recycling energy into a bootstrap capacitor?  With the Allegro isolated drivers that's taken care of for you.  Infinite ON and OFF time capability comes as standard.

Separate pull-up/pull-down pins

This enables the system designer to freely choose a resistor value for turn ON (pull-up) and turn OFF (pull-down).



Bodo's Power System 12 月号で GaN Systems が Allegro ドライバーを推奨

非常に効果的な GaN 設計を実現するための最初のステップとして AHV85110 (HEY1011) ゲート ドライバーが推奨されています。



こちらから記事全文をお読みください。

優れたモジュールの作成

スイッチ ロスの減少

伝搬時間の短縮 = 短いデッドタイム

信頼性の向上

堅牢な設計とコンポーネント数の減少は信頼性の向上を意味します

容易な設計

電源コンバータ用にカスタム絶縁電源を設計する必要がありません。nbsp; これらの Allegro ドライバーを使用して既に用意されています

モジュールの重量の削減

追加の磁気、追加の巻き線、追加のシリコンと受動素子、個別の絶縁電源モジュールなどの追加のコンポを排除しています
