APS11203KMDALX-1PL0
- supply_voltage_min_v
- 2.7
- supply_voltage_max_v
- 26
- output
- Voltage
- sensor_type
- 1D Planar
- temp_ranges
- -40°C to 125°C
- asil_rated
- No
- typical_bop
- 15
- typical_brp
- 10
- market
- Industrial
Switches and Latches
24V Hall-effect Switches for Automotive and Industrial Applications
APS11203
Markets Served
The APS11203 is a third generation Hall-effect switch featuring chopper-stabilization for precision performance over both industrial and automotive temperature ranges. Models are available supporting omnipolar and unipolar operation with both high and low polarity output options. The APS11203 incorporates Allegro’s latest design and manufacturing technologies to deliver an unprecedented level of performance and value across automotive, industrial and consumer applications.
Product Details
Product Details
Top Features
- 2.7 to 26V operation
- AEC-Q100 qualified
- Omnipolar and unipolar switch threshold options
- High and low sensitivity magnetic switch point options
- Choice of output polarity
- Chopper stabilization
- Low switch point drift over temperature
- Insensitive to physical stress
- Open drain output
- Solid-state reliability
- Industry-standard package and pinout
Target Application
- Seatbelt
- White Goods
- Building Automation
- Robotics
- Throttle Position
Part Number Specifications and Availability
