120 kHz Hall-effect Current Sensor with Overcurrent Fault in SOIC-8 and QFN-12 Packages

ACS71240

Markets Served

The ACS71240 offers a robust current sensing solution for automotive and industrial shunt-replacement applications, featuring differential sensing for common-mode rejection and a fast overcurrent fault output for reliable operation.

View Datasheet

Product Details

Top Features

AEC-Q100 qualified
Overcurrent FAULT with a Factory Programmable trip range of 50% to 200% of full-scale current
Reduced Power Loss:
- 0.6 mΩ internal conductor resistance on QFN package
- 1.2 mΩ internal conductor resistance on SOIC8 package
Small footprint, low-profile QFN and SOIC8 packages suitable for space-constrained applications
120 kHz bandwidth
100 V_RMSworking voltage for functional isolation (QFN package)
297 V_RMS working voltage for basic isolation (SOIC-8 package)

Target Application

Part Number Specifications and Availability

View Full Specification Details

ACS71240KEXBLT-005B3-096-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-005B3-230-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-010B3

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-010B3-115-S

basic_isolation_working_voltage_vrms: 100
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±10
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-010B3-S

basic_isolation_working_voltage_vrms: 100
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±10
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-010B5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-010B5-S

basic_isolation_working_voltage_vrms: 100
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±10
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-020B5-150L

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-020B5-150L-S

basic_isolation_working_voltage_vrms: 100
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±20
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-020B5-S

basic_isolation_working_voltage_vrms: 100
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±20
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-030B3

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-030B3-167L-S

basic_isolation_working_voltage_vrms: 100
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±30
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-030B3-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±30
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-030B5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-030B5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±30
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-045B5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-045B5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±45
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-050B3

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-050B3-120

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-050B3-120-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±50
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-050B3-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±50
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-050B5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-050B5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: ±50
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240KEXBLT-050U5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240KEXBLT-050U5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: 0.6
current_measurement_range_a: 50
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 125°C
package: 12-Pin QFN
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240LLCBTR-010B3

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-010B3-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: 2400
creepage_mm: 4.2
clearance_mm: 4.2
primary_conductor_resistance_mohm: 1.2
current_measurement_range_a: ±10
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 150°C
package: 8-Pin SOIC
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240LLCBTR-020U5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-020U5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: 2400
creepage_mm: 4.2
clearance_mm: 4.2
primary_conductor_resistance_mohm: 1.2
current_measurement_range_a: 20
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 150°C
package: 8-Pin SOIC
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240LLCBTR-025B3

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-030B3

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-030B3-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: 2400
creepage_mm: 4.2
clearance_mm: 4.2
primary_conductor_resistance_mohm: 1.2
current_measurement_range_a: ±30
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 150°C
package: 8-Pin SOIC
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240LLCBTR-045B5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-045B5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: 2400
creepage_mm: 4.2
clearance_mm: 4.2
primary_conductor_resistance_mohm: 1.2
current_measurement_range_a: ±45
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 150°C
package: 8-Pin SOIC
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240LLCBTR-050B3

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-050B3-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: 2400
creepage_mm: 4.2
clearance_mm: 4.2
primary_conductor_resistance_mohm: 1.2
current_measurement_range_a: ±50
bandwidth_khz: 120
supply_voltage_v: 3.3
temp_ranges: -40°C to 150°C
package: 8-Pin SOIC
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240LLCBTR-050B5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-050B5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: 2400
creepage_mm: 4.2
clearance_mm: 4.2
primary_conductor_resistance_mohm: 1.2
current_measurement_range_a: ±50
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 150°C
package: 8-Pin SOIC
market: Automotive, Industrial
features: Overcurrent Fault

ACS71240LLCBTR-050U5

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: -
creepage_mm: -
clearance_mm: -
primary_conductor_resistance_mohm: -
current_measurement_range_a: -
bandwidth_khz: -
supply_voltage_v: -
temp_ranges: -
package: -
market: -
features: -

ACS71240LLCBTR-050U5-S

basic_isolation_working_voltage_vrms: -
isolation_voltage_vrms: 2400
creepage_mm: 4.2
clearance_mm: 4.2
primary_conductor_resistance_mohm: 1.2
current_measurement_range_a: 50
bandwidth_khz: 120
supply_voltage_v: 5
temp_ranges: -40°C to 150°C
package: 8-Pin SOIC
market: Automotive, Industrial
features: Overcurrent Fault

Discover Allegro's Advanced Magnetic Current Sensors!

Upgrade your designs with efficient, compact, and integrated solutions. Simplify your circuits and reduce component count with Allegro's innovative sensor technology.

Replace the Shunt
