A1468LK-T
- direction_info
- Speed
- physical_interface
- 3-Wire (voltage)
- technology
- Hall
- package
- 4-Pin SIP
- market
- Automotive, Industrial
Magnetic Speed Sensors
True Zero-Speed Differential Hall-Effect Sensor IC for Ring Magnet Applications
A1468
Markets Served
The A1468 provides precise speed and position sensing for ring magnet applications, featuring true zero-speed operation, continuous calibration, and a wide operating voltage range (4V-26.5V) for robust performance.
Product Details
Product Details
Top Features
- 4.0 to 26.5 V supply operating range
- Minimum differential field 20 Gpk-pk
- Running mode calibration for continuous optimization
- Single chip IC for high reliability
- Precise duty cycle signal throughout operating temperature range
- Large operating air gaps
- Automatic Gain Control (AGC) for air-gap–independent switchpoints
- Automatic Offset Adjustment (AOA) for signal processing optimization
- True zero-speed operation
- Undervoltage lockout
- Reverse battery protection
- Scan and IDDQ for increased test coverage
Target Application
Part Number Specifications and Availability
View Full Specification Details
A1468LKTN-T
- direction_info
- -
- physical_interface
- -
- technology
- -
- package
- -
- market
- Automotive, Industrial
A1468LKTS-T
- direction_info
- -
- physical_interface
- -
- technology
- -
- package
- -
- market
- Automotive, Industrial
