Brushless DC Drivers

48V Sensorless Code-Free FOC BLDC Motor Controller with Integrated Gate Driver

A89333

Markets Served

The A89333 simplifies the design of high-efficiency, low-noise 48V BLDC motor drives. It features integrated field-oriented control (FOC), sensorless operation, and an integrated gate driver, reducing component count and design complexity.

View Datasheet
Evaluation Board

Product Details

Top Features

  • 90V maximum rating with integrated buck regulator for high efficiency
  • Fully integrated single-shunt sensorless FOC controller (code-free)
  • Speed, torque, and power mode operation
  • Slew-rate control for electromagnetic-interference (EMI) mitigation
  • Ultra-quiet low-speed operation
Target Application

Part Number Specifications and Availability

View Full Specification Details

A89333GECSR

supply_voltage_min_v
7
supply_voltage_max_v
90
architecture
Gate Driver
control_interface
Analog, PWM Speed
rds_on
Pre-Driver
commutation
Field Oriented Control (FOC)
motor_positioning_method
Sensorless
number_of_bridges
Half-Bridge x3
temperature
-40°C to 105°C
package
28-Pin QFN
market
Industrial

A89333GECSR-1

supply_voltage_min_v
7
supply_voltage_max_v
90
architecture
Gate Driver
control_interface
Analog, PWM Speed
rds_on
Pre-Driver
commutation
Field Oriented Control (FOC)
motor_positioning_method
Sensorless
number_of_bridges
Half-Bridge x3
temperature
-40°C to 105°C
package
28-Pin QFN
market
Industrial
